Analog Devices Inc. ADG1206L/1207L Multiplexer Switch ICs

Analog Devices Inc. ADG1206L/1207L Multiplexer Switch ICs are monolithic iCMOS^® analog multiplexers comprising sixteen single and eight differential channels. The ADG1206L switches one of sixteen inputs to a common output, according to the 4‑bit binary address lines A0, A1, A2, and A3. The ADG1207L switches one of eight differential inputs to a common differential output, according to the 3-bit binary address lines A0, A1, and A2. These ADG1206L/1207L multiplexer switch ICs feature EN input to enable or disable. The multiplexers feature 1.5pF off capacitance, 120Ω on resistance, and are 1.2V and 1.8V JEDEC standard compliant. Typical applications include audio and video routing, automatic test equipment, data acquisition systems, battery-powered systems, sample-and-hold systems, and communication systems.
