Omron Electronics B5W-LA01 Light Convergent Reflective Sensor

Omron Electronics B5W-LA01 Light Convergent Reflective Sensor provides robust performance with little influence from sensing object color or material. This convergent-mode sensor uses a lens system to focus the emitter and the receiver elements to an exact point in front of the sensor. B5W-LA01 is less sensitive to background reflections compared with diffuse-mode sensors. B5W-LA01 detects objects with mirror reflective surfaces and transparent objects. This Omron Electronics sensor also provides a 70mm maximum sensing distance and analog voltage output. Target applications include home appliances, vending machines, office automation equipment, and ATMs.
