KYOCERA AVX Gas-Tight Wire-to-Board IDC Connectors
KYOCERA AVX Gas-Tight Wire-to-Board Insulation Displacement Connectors (IDC) are surface-mount connectors that facilitate simplicity in connecting individual wires directly to a PCB. The dual IDC contact system employs a redundant gas-tight interface to the wire that has been tested for reliability up to automotive levels of temperature, shock, and vibration. These KYOCERA AVX connectors are available in various heights, termination styles, and configurations.
Features
- IDC contact provides a gas-tight connection to the PCB for long-term reliability
- Tested to automotive levels for shock, vibration, and temperature cycling for reliability
- Reduced total applied cost versus solder or crimp processes
- Low and high volume assembly tools to match production volume
- High-temperature insulator capable to 260°C reflow soldering process
Applications
- Connecting discrete wire directly to the PCB
- Bringing power and signals onto a PCB
- Daisy-chaining PCBs together to create a continuous string of boards
Additional Resources
Featured Gas-Tight Connectors
KYOCERA AVX 9175 Gas-Tight Wire-to-Board IDC Connectors
Connects individual wires ranging from 28AWG to 26AWG directly to a PCB.
KYOCERA AVX 9176 Gas-Tight Wire-to-Board IDC Connectors
Connects individual 18AWG-14AWG wires directly to PCB in harsh automotive & industrial applications.
KYOCERA AVX 9177 Gas-Tight Wire-to-Board IDC Connectors
Connects individual wires ranging from 28AWG to 14AWG directly to a PCB.
Related Connectors
KYOCERA AVX Wire-to-Board Insulation Displacement Connectors
Offered in 28AWG to 12AWG and 1A to 15A ranges, high-performance phosphor bronze construction.
KYOCERA AVX Wire-To-Board Connectors
Low-profile, cost-effective contact solution for connecting discrete wires to a PCB.
