Infineon Technologies PSOC™ 4 HVPA-SPM 1.0 Smart Battery-Pack Monitor
Infineon Technologies PSOC™ 4 HVPA-SPM 1.0 Smart Battery-Pack Monitor is designed for high-voltage Li-ion battery management in electric vehicles (xEVs), providing the high-precision monitoring of current, voltage, and temperature. This advanced microcontroller combines safety, programmability, and precision, while supporting zonal architectures and the transition to software-defined vehicles (SDVs). The fully integrated design ensures reliable battery performance and improves both state-of-health (SoH) and state-of-charge (SoC) accuracy. The built-in 32-bit Arm® Cortex®-M0+ processor enables faster data processing and reduces the load on the central electronic control unit (ECU). Infineon Technologies PSOC 4 HVPA-SPM 1.0 Smart Battery-Pack Monitor is fully compliant with ASIL D (ISO 26262) safety standards, delivering robust and reliable operation in critical high-voltage battery systems.
Features
- Smart battery-pack monitor for safe and secure battery management systems
- Robust and reliable operation
- Supports zonal architectures and transition to SDVs
- Fully integrated design with key features that bring advanced intelligence, safety, and efficiency to BMS
- High-precision monitoring of current, voltage, and temperature
- Improves accuracy of SoC and SoH
- Designed for high-voltage Li-ion battery management in xEVs
- Combines precision, safety, and programmability
- Delivers advanced edge intelligence for faster data processing, reducing load on central ECU
- Users can reuse existing AUTOSAR MCAL CAN software stacks
- Eliminates need for additional MCU in battery junction box
Specifications
- 32-bit Arm Cortex-M0+ MCU
- 128KB code flash, 16KB data flash, and 8KB SRAM
- 16-bit ADCs for V and I sensing
- OCD comparators
- Daisy-chain interface (Iso UART 1.0)
- Isolation resistance
- EIS support
- ISO 26262 ASIL-D compliant AFE
- BMS gateway via CAN-FD interface
- 48-pin wettable flank QFN package
- Peripheral driver library and SafeTlib
Designed for xEVs
