Diodes Incorporated AP61402/AP61402Q Synchronous Buck Converters

Diodes Incorporated AP61402/AP61402Q Synchronous Buck Converters are devices that operate at 2.3V to 5.5V input voltage and 4A output current. These buck converters are high-efficiency devices that help to extend battery life in portable applications and reduce heat generation. The AP61402 integrates both high-side and low-side power MOSFETs, minimizing the external component count and simplifying board design. These devices operate at a 2MHz switching frequency and 0.5V ±2% reference voltage. The AP61402Q converters are suitable for automotive applications requiring specific change control, AEC-Q100 qualified, PPAP capable, and manufactured in IATF16949 certified facilities. The AP61402 converters are ideal for automotive power systems, network video cameras, general-purpose POL supplies, hard disk drives, wireless routers, and automotive infotainment.
