Bel Magnetic Solutions MagJack® Integrated Connector Modules
Bel Magnetic Solutions MagJack® Integrated Connector Modules (ICMs) address a combination of requirements, meeting IEEE 802.3, TIA-968-A, and FCC-Part 15 standards. This combination eases the implementation of medium-dependent interfaces. The MagJack series allows connection from the physical layer to the physical medium. Bel Magnetic Solutions MagJack Integrated Connector Modules consist of an RJ45 connector, transformers, capacitors, and resistors that provide isolation and EMI suppression.
Features
- Manufactured with minimal numbers of solder connections to increase reliability over time
- 100% tested
- Multiple solutions can be integrated into one connector series
- Shielded magnetics
- Shorter PCB traces
- Over 50% space savings on a PCB per RJ port
- Vertical-mount packaging available
- RoHS compatible
Featured Products
Bel Magnetic Solutions MagJack® 10G Integrated Connector Modules
Low profile connector modules that support 10GBase-T Ethernet applications.
Bel Magnetic Solutions 08G0-281D-GUA MagJack 1000BaseT
Press-fit mountable versions of the traditional wave or reflow soldering-based parts.
TRP Connector / Bel MagJack™ Press-Fit Integrated Connector Modules
Features RoHS 6/6 compliancy, UL recognition, and a 0°C to +70°C operating temperature range.
TRP Connector / Bel Specialty Integrated Connector Modules (ICMs)
Combine the Ethernet filtering solution within the connector.
Related Products
Bel 1xN Port MagJack® Integrated Connector Modules
1- through 8-port low-density RJ45 connectors with integrated Ethernet magnetics inside the package.
Bel 2xN Port Integrated Connector Modules
2- through 18-port high-density RJ45 connectors with integrated Ethernet magnetics in the package.
