Amphenol Anytek YK42A Single-Row Barrier Terminal Blocks
Amphenol Anytek YK42A Single-Row Barrier Terminal Blocks feature wire-ready raised screws and a dual-barrier design. These Amphenol Anytek terminal blocks are designed for versatile electronic and electrical OEM applications. The YK42A is engineered to meet UL safety standards and features a robust structure and easy installation. The 8.25mm pitch YK441 supports high-current and high-voltage applications for reliable long-term performance. The series features integrated dual barriers on both sides of each screw, providing enhanced electrical insulation and mechanical protection. The factory-set raised screws allow wires to be inserted and tightened directly, improving wiring efficiency and almost doubling connection speed.
Features
- High power rating
- 8.25mm pitch
- Up to 20A high current rating
- 300V voltage rating
- Ideal for medium- to high-power connections
- Dual-barrier design
- Integrated dual barriers on both sides of each screw
- Provides enhanced electrical insulation and mechanical protection
- Prevents short circuits and wire misconnection
- Wire-ready raised screws
- Factory-set raised screws allow wires to be inserted and tightened directly
- Significantly improves wiring efficiency and almost doubles connection speed
Applications
- OEM electronic and electrical equipment
- Industrial
- Automation
- Electronic systems
Additional Resources
Key Product Highlight
Dimensions
