Abracon AVR-1Z090509S Vertically Assembled Power Inductors

Abracon AVR-1Z090509S Vertically Assembled Power Inductors are designed with a low DC Resistance (DCR), ensuring high circuit efficiency by minimizing energy loss. These inductors boast a high-temperature current rating, ensuring reliable operation in elevated thermal conditions. The AVR-1Z090509S inductors also boast a high saturation current rating, ensuring consistent performance even under heavy loads. These inductors feature a 90nH to 330nH inductance range, 0.125mΩ±10% DC resistance, and 63A temperature rise current. The AVR-1Z090509S inductors measure 9mm x 5.2mm x 9.4mm and are compliant with Moisture Sensitivity Level-1 (MSL-1) and RoHS/RoHS II. Typical applications include single and multiphase DC-DC converters, Voltage Regulator Modules (VRMs), renewable energy, power inverters, DC links, Electric Vehicles (EVs), telecom infrastructure, and data centers.
