LSS-120-02-L-DV-A-K-TR

Name: Samtec LSS-120-02-L-DV-A-K-TR
Brand: Samtec
SKU: 200-LSS12002LDVAKTR
Price: 3.44 EUR
Availability: OutOfStock

Images are for reference only
See Product Specifications

Mouser No:

200-LSS12002LDVAKTR

Mfr. No:

LSS-120-02-L-DV-A-K-TR

Mfr.:

Samtec

Description:

Board to Board & Mezzanine Connectors 0.635 mm Razor Beam High-Speed Hermaphroditic Terminal/Socket Strip

Datasheet:

LSS-120-02-L-DV-A-K-TR Datasheet (PDF)

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

Availability

Stock:: 0

You can still purchase this product for backorder.

An unexpected error occurred. Please try again later.
On Order:: 2.298

Expected 6/22/2026

11.550

4.900

Expected 7/8/2026

6.650

Expected 8/3/2026
Factory Lead Time:: 1

Week Estimated factory production time for quantities greater than shown.

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

-,-- €

Ext. Price:

-,-- €

Est. Tariff:

Packaging:

Full Reel (Order in multiples of 350)

Cut Tape

MouseReel™ (+5,00 €)

Pricing (EUR)

Qty.	Unit Price	Ext. Price
Cut Tape / MouseReel™ ^†
	3,44 €	3,44 €
	3,23 €	80,75 €
	3,06 €	153,00 €
	3,02 €	302,00 €
Full Reel (Order in multiples of 350)
	2,79 €	976,50 €
	2,49 €	1.743,00 €
	2,23 €	5.463,50 €
	2,00 €	9.800,00 €
9.800	Quote

† A MouseReel™ fee of 5,00 € will be added and calculated in your basket. All MouseReel™ orders are non-cancellable and non-returnable. ↩

Alternative Packaging

Mfr. Part No.:

LSS-120-02-L-DV-A-K

Packaging:

Tray

Availability:

In Stock

Price:

3,36 €

Min:

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Samtec
Product Category:	Board to Board & Mezzanine Connectors
RoHS:
Product:	Connectors
Number of Positions:	40 Position
Pitch:	0.635 mm (0.025 in)
Number of Rows:	2 Row
Termination Style:	Solder
Mounting Angle:	Vertical
Stack Height:	9 mm, 10 mm, 12 mm
Current Rating:	1.7 A
Voltage Rating:	300 VAC
Maximum Data Rate:	25 Gbps
Minimum Operating Temperature:	- 55 C
Maximum Operating Temperature:	+ 125 C
Contact Plating:	Gold
Contact Material:	Phosphor Bronze
Housing Material:	Liquid Crystal Polymer (LCP)
Series:	LSS
Packaging:	Reel
Packaging:	Cut Tape
Packaging:	MouseReel
Application:	Power, Signal
Brand:	Samtec
Data Rate:	25 Gbps
Mounting Style:	SMD/SMT
Product Type:	Board to Board & Mezzanine Connectors
Factory Pack Quantity:	350
Subcategory:	Board to Board & Mezzanine Connectors
Tradename:	Razor Beam
Unit Weight:	200 mg
