LPAM-20-01.5-S-08-2-K-TR

Name: Samtec LPAM-20-01.5-S-08-2-K-TR
Brand: Samtec
SKU: 200-LPAM20015S082KTR
Price: 17.96 EUR
Availability: InStock

Images are for reference only
See Product Specifications

Mouser No:

200-LPAM20015S082KTR

Mfr. No:

LPAM-20-01.5-S-08-2-K-TR

Mfr.:

Samtec

Description:

Board to Board & Mezzanine Connectors .050 LP Array High-Speed High-Density Low Profile Open-Pin-Field Array

Datasheet:

LPAM-20-01.5-S-08-2-K-TR Datasheet (PDF)

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

More Information

Learn more about Samtec LPAM-20-01.5-S-08-2-K-TR

In Stock: 6

Stock:: 6 Can Dispatch Immediately

An unexpected error occurred. Please try again later.
Factory Lead Time:: 1 Week Estimated factory production time for quantities greater than shown.

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

-,-- €

Ext. Price:

-,-- €

Est. Tariff:

Pricing (EUR)

Qty.	Unit Price	Ext. Price
	17,96 €	17,96 €
	17,17 €	171,70 €
	16,53 €	413,25 €
	15,32 €	766,00 €
	13,16 €	1.316,00 €
Full Reel (Order in multiples of 300)
	11,20 €	3.360,00 €
	10,91 €	6.546,00 €

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Samtec
Product Category:	Board to Board & Mezzanine Connectors
RoHS:
Product:	Headers
Number of Positions:	160 Position
Pitch:	1.27 mm (0.05 in)
Number of Rows:	8 Row
Termination Style:	Crimp
Mounting Angle:	Vertical
Stack Height:	4.5 mm, 5 mm
Current Rating:	2.2 A
Voltage Rating:	250 VAC
Maximum Data Rate:	28 Gbps
Minimum Operating Temperature:	- 55 C
Maximum Operating Temperature:	+ 125 C
Contact Plating:	Gold
Contact Material:	Copper Alloy
Housing Material:	Liquid Crystal Polymer (LCP)
Series:	LPAM
Packaging:	Reel
Packaging:	Cut Tape
Brand:	Samtec
Country of Assembly:	Not Available
Country of Diffusion:	Not Available
Country of Origin:	US
Data Rate:	28 Gbps
Product Type:	Board to Board & Mezzanine Connectors
Factory Pack Quantity:	300
Subcategory:	Board to Board & Mezzanine Connectors
Tradename:	LP Array
Unit Weight:	4,732 g
