LPAM-20-01.5-L-04-2-K-TR

Name: Samtec LPAM-20-01.5-L-04-2-K-TR
Brand: Samtec
SKU: 200-LPAM20015L042KTR
Price: 11.27 EUR
Availability: InStock

Images are for reference only
See Product Specifications

Mouser No:

200-LPAM20015L042KTR

Mfr. No:

LPAM-20-01.5-L-04-2-K-TR

Mfr.:

Samtec

Description:

Board to Board & Mezzanine Connectors .050 LP Array High-Speed High-Density Low Profile Open-Pin-Field Array

Datasheet:

LPAM-20-01.5-L-04-2-K-TR Datasheet (PDF)

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

More Information

Learn more about Samtec LPAM-20-01.5-L-04-2-K-TR

In Stock: 178

Stock:: 178 Can Dispatch Immediately

An unexpected error occurred. Please try again later.
Factory Lead Time:: 3 Weeks Estimated factory production time for quantities greater than shown.

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

-,-- €

Ext. Price:

-,-- €

Est. Tariff:

Pricing (EUR)

Qty.	Unit Price	Ext. Price
	11,27 €	11,27 €
	10,78 €	107,80 €
	10,37 €	259,25 €
	9,61 €	480,50 €
	8,26 €	826,00 €
	7,03 €	1.757,50 €
Full Reel (Order in multiples of 450)
	7,03 €	3.163,50 €
	6,85 €	6.165,00 €

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Samtec
Product Category:	Board to Board & Mezzanine Connectors
RoHS:
Product:	Headers
Number of Positions:	80 Position
Pitch:	1.27 mm (0.05 in)
Number of Rows:	4 Row
Termination Style:	Crimp
Mounting Angle:	Vertical
Stack Height:	4.5 mm, 5 mm
Current Rating:	2.2 A
Voltage Rating:	250 VAC
Maximum Data Rate:	28 Gbps
Minimum Operating Temperature:	- 55 C
Maximum Operating Temperature:	+ 125 C
Contact Plating:	Gold
Contact Material:	Copper Alloy
Housing Material:	Liquid Crystal Polymer (LCP)
Series:	LPAM
Packaging:	Reel
Packaging:	Cut Tape
Brand:	Samtec
Country of Assembly:	Not Available
Country of Diffusion:	Not Available
Country of Origin:	US
Data Rate:	28 Gbps
Product Type:	Board to Board & Mezzanine Connectors
Factory Pack Quantity:	450
Subcategory:	Board to Board & Mezzanine Connectors
Tradename:	LP Array

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0

Filter Document:

Specification Sheets

Technical Resources

Test Report (PDF)

TARIC:: 8536693000
CNHTS:: 8536901900
CAHTS:: 8536690020
USHTS:: 8536694040
JPHTS:: 853669000
KRHTS:: 8536691000
MXHTS:: 8536699999
BRHTS:: 85366990
ECCN:: EAR99
