LPAF-30-03.0-L-04-2-K-TR

Name: Samtec LPAF-30-03.0-L-04-2-K-TR
Brand: Samtec
SKU: 200-LPAF30030L042KTR
Price: 12.14 EUR
Availability: InStock

Images are for reference only
See Product Specifications

Mouser No:

200-LPAF30030L042KTR

Mfr. No:

LPAF-30-03.0-L-04-2-K-TR

Mfr.:

Samtec

Description:

Board to Board & Mezzanine Connectors .050 LP Array High-Speed High-Density Low Profile Open-Pin-Field Array

Datasheet:

LPAF-30-03.0-L-04-2-K-TR Datasheet (PDF)

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

More Information

Learn more about Samtec LPAF-30-03.0-L-04-2-K-TR

In Stock: 140

Stock:: 140 Can Dispatch Immediately

An unexpected error occurred. Please try again later.
Factory Lead Time:: 11 Weeks Estimated factory production time for quantities greater than shown.

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

-,-- €

Ext. Price:

-,-- €

Est. Tariff:

Pricing (EUR)

Qty.	Unit Price	Ext. Price
	12,14 €	12,14 €
	11,61 €	116,10 €
	11,18 €	279,50 €
	10,36 €	518,00 €
	8,90 €	890,00 €
	7,57 €	1.892,50 €
Full Reel (Order in multiples of 550)
	6,49 €	3.569,50 €

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Samtec
Product Category:	Board to Board & Mezzanine Connectors
RoHS:
Product:	Sockets
Number of Positions:	120 Position
Pitch:	1.27 mm (0.05 in)
Number of Rows:	4 Row
Termination Style:	Crimp
Mounting Angle:	Straight
Current Rating:	2.2 A
Voltage Rating:	250 VAC
Contact Plating:	Gold
Contact Material:	Copper Alloy
Housing Material:	Liquid Crystal Polymer (LCP)
Series:	LPAF
Packaging:	Reel
Packaging:	Cut Tape
Application:	Power, Signal
Brand:	Samtec
Country of Assembly:	Not Available
Country of Diffusion:	Not Available
Country of Origin:	US
Mounting Style:	SMD/SMT
Product Type:	Board to Board & Mezzanine Connectors
Factory Pack Quantity:	550
Subcategory:	Board to Board & Mezzanine Connectors
Tradename:	LP Array
